Compressed Air Systems

Champion CRH50 Refrigerated High Inlet Temperature Dryer

$3,651.00

27-CRH501

Add to cart

Request a call



Champion specializes in delivering the best compressed air quality to your working environment. Removing water, solid particulates and oil from compressed air has many benefits which all lead to increased productivity and reduced overhead costs. The CRH Series is designed to work with reciprocating air compressors through 30 horsepower, and is ideally suited for body shops, auto service centers and light industrial facilities. The space saving design integrates a refrigerated air dryer and a particle/oil removal filter all in one compact package. There is no need for an additional after-cooler because the CRH Series accepts air directly from your reciprocating compressor. This allows you to receive clean compressed air while saving floor space.



Features

  • Reliable 50°F pressure dew point provides dry air.
  • Stainless steel heat exchangers with high-heat transfer coefficients allow inlet temperatures to 180°F (82°C)
  • Integral CFF Series Grade B Separator/Filter -- removes solid particles to 3 micron and oil to 5 ppm.
  • Zero air-loss condensate drains with reliable pneumatic operation.
  • Environmentally-friendly R407c refrigeration system maintains reliable dew point temperatures automatically Hermetic, no-maintenance refrigeration compressors.
  • Fan switch allows operation in low (35°F, 2°C) ambient temperatures.
  • Power cord with molded plug.
  • Instrumentation has convenient on/off switch for start-up and fault light for system malfunction.
  • CSA certified 115 volt models.
  • Maintenance kits available for ease of service.



Technical

Weight approx. 150 lbs
Dimensions (L x W x H) 37 x 17 x17 inch
Power supply 115 / 60 / 1ph V/Hz/A
