Fire-Ball300 15:1 Portable 35 lb Pneumatic Undercoating/Rust-Proofing Pump Package

$2,056.00

11-222077

Add to cart

Request a call

Click to view California Proposition 65 warning

Portable undercoating package for 35 lb (16 kg) container includes pump (206405), dispense kit (222079), tip (286517), 15 ft (4.6 m) hose length, cover (222058).

Features

• Maximum Working Pressure: 2700 psi (186 bar)
• Fluid pressure ratio: 15:1
• Air operating range: 40 to 180 psi (3 to 12 bar)
• Air motor effective diameter: 3 in. (76 mm)
• Stroke: 3 in. (76 mm)
• Air consumption: 17 cfm/gallon pumped at 100 psi
• Pump cycles per gallon (liter): 90 (24)
• Delivery: 0.66 gallons/minute (3 liters/minute)
• Maximum recommended pump speed: 66 cycles/min;0.7 gpm (32 liter/min)
• Recommended speed for optimum pump life: 15 to 25 cycles per min
• Wetted parts: Carbon Steel, Brass, Copper, Aluminum, PTFE, Nitrile Rubber, Leather
