The L Series oil-injected rotary screw compressors provide a range that combines high performance, low operating costs and reliability with ease of installation and servicing. Industries both large and small rely on Champion rotary screw compressors for a constant supply of high-quality compressed air.

Specifications and Features:

• 30HP
• Pressure at 190 PSIG
• 92 CFM at 190 PSIG
• Fixed Speed
• 120 Gallon Horizontal Tank Mount
• Mounted CNC150 Refrigerated Dryer
• 2-Year Warranty
• Factory Filled with CompLube 8000



Features

• Compact design which gives you a small footprint.
• TEFC High Efficiency Motor.
• Quiet Enclosure to reduce sound levels.
• Wye/Delta Starter.
• Delcos Microprocessor based control system.
• Automatic belt tensioning system.



Technical

Weight approx.	1,604	lbs
Power supply	208-230, 460 / 60 / 3ph	V/Hz/A
Dimensions (L x W x H)	80 x 32 x 74	inch
