The 12k 2-Post automotive/general-purpose lift is versatile. Multi-stack pad adapters are standard, making it easy to reach the vehicle manufacturer’s pick-up points on either cars or trucks. ANSI / ALI certified to the current lift standard.



Features

• Superior symmetric two post lift.
• Light / Medium duty lifting capactiy 12,000 lbs (5443kg).
• Overall height can be adjusted (at time of installation) to accomodate taller vehicles.
• Heavy-duty two stage front and read lift arms.
• Insert adjustable screw lifting pads with rubber contact surface for quick and easy vehicle setup.
• Rubber door guards secure against door to column damage.
• Single point safety lock release system.
• Taller carriages for smooth performance.
• 71" cylinder stroke for higher under vehicles work area.
• Padded overhead safety shut off bar for improved vehicle clearance.
• ANSI / ALI certified to the current lift standard.



Technical

Load carrying capacity	12000	lbs
Effective height	159.5-168.5	inch
Lifting height	78.125	inch
Lifting/lowering time approx.	66 second rise time	s
Weight approx.	1750	lbs
Color	Red
Track width	137.75	inch
Power supply	208-230V/60Hz/1Ph	V/Hz/A
Dimensions (L x W x H)	48x137.75x166-175	inch



Options

119-EELR537AB

12K 2-Post Automotive Service Lift, Blue

$8,414.00

Add to cart



Accessories

119-EAK0299T22A

Stack Adapter Kit

$286.00

Add to cart
