Fluid And Lube Handling
Graco 206700 Fire-Ball® 300 15:1 - Pneumatic Grease Pump
$1,918.00
11-206700
Click to see additional Options / Models / Accessories Available
Options
_web.jpg)
Click to view California Proposition 65 warning
For nearly 60 years, Graco Fire-Ball pumps have been a mainstay in the lubrication marketplace for durability
and long life. Designed for the toughest applications, the Fire-Ball 300 air-powered grease pumps and packages are perfect for high pressure grease dispense and transfer, with continuous duty flow rates up to .7 lbs./minute. The pump featured is a 400 lb pneumatic grease pump, typically handling grease up to NLGI #2 in automotive dealerships, fast lube centers, and service shops.
Features
- Thick cast aluminum air motor housing with a corrosion-resistant design offers unmatched durability
- Fewer moving parts in air motor assembly means less down time and low repair costs
- In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life
- Non-metallic poppet valves offer positive sealing performance, even with contaminated environments for long life without repair
- 7 Year Warranty. See Manufacturers Website for details.
- Approximate Free Flow Rate: @ 100 psi 7.5 lb./min (3.4 kg/min)
- Approximate Air Use and Flow @ 100 psi (80 cpm): 14 scfm @ 6.5 lb./min (0.40 @ 2.9 kg/min)
- Air Inlet: 3/8 in npt (f)
- Fluid Outlet: 1/4 in npt (f)
- Air Operation Range: 40-180 psi (3-10 bar)
- Cycles per Pound/Kg: 12.4 cpp / 27 cpk
- Wetted Parts: CS, AL, leather, PTFE, rubber
Technical
| Weight approx. | 23 | lbs |
| Dimensions (L x W x H) | 52.8 x 9.6 x 10.8 | inch |
Options
| 11-206405 | Graco 206405 Fire-Ball ®300 15:1 - 35 lb Pneumatic Grease Pump | $1,872.00 | Add to cart |
| 11-206699 | Graco 206699 Fire-Ball ®300 15:1 - 120 lb Pneumatic Grease Pump | $1,933.00 | Add to cart |
